Styczniki instalacyjne ESB są głównie stosowane w budynkach w celu przełączania i sterowania oświetleniem, ogrzewaniem, wentylacją, silnikiem i pompami. Zostały opracowane tak, aby pasowały do modułowych elementów szyny DIN firmy ABB oraz aby można było je łatwo zintegrować w dedykowanych panelach. Styczniki EN posiadają wbudowany przełącznik dwustabilny do wyboru trybu ręcznego lub automatycznego obsługi.
Główne korzyści
Cechy charakterystyczne
Styczniki modułowe ESB. Tabela wykonań:
| Symbol stycznika |
Numer katalogowy |
Prąd znamionowy |
Napięcie zasilające cewki |
Konfiguracja styków |
EAN |
| Styczniki ESB16 | |||||
| ESB16-02N-01 | 1SBE111111R0102 | 16A | 24V AC/DC | 2NC | 3471523004313 |
| ESB16-02N-02 | 1SBE111111R0202 | 16A | 42V AC/DC | 2NC | 3471523004344 |
| ESB16-02N-03 | 1SBE111111R0302 | 16A | 48V AC/DC | 2NC | 3471523004375 |
| ESB16-02N-04 | 1SBE111111R0402 | 16A | 110V AC/DC | 2NC | 3471523004405 |
| ESB16-02N-05 | 1SBE111111R0502 | 16A | 240V AC/DC | 2NC | 3471523004436 |
| ESB16-02N-06 | 1SBE111111R0602 | 16A | 230V AC/DC | 2NC | 3471523004467 |
| ESB16-02N-07 | 1SBE111111R0702 | 16A | 400V AC/DC | 2NC | 3471523004498 |
| ESB16-02N-14 | 1SBE111111R1402 | 16A | 12V AC/DC | 2NC | 3471523004528 |
| ESB16-11N-01 | 1SBE111111R0111 | 16A | 24V AC/DC | 1NO+1NC | 3471523004320 |
| ESB16-11N-02 | 1SBE111111R0211 | 16A | 42V AC/DC | 1NO+1NC | 3471523004351 |
| ESB16-11N-03 | 1SBE111111R0311 | 16A | 48V AC/DC | 1NO+1NC | 3471523004382 |
| ESB16-11N-04 | 1SBE111111R0411 | 16A | 110V AC/DC | 1NO+1NC | 3471523004412 |
| ESB16-11N-05 | 1SBE111111R0511 | 16A | 240V AC/DC | 1NO+1NC | 3471523004443 |
| ESB16-11N-06 | 1SBE111111R0611 | 16A | 230V AC/DC | 1NO+1NC | 3471523004474 |
| ESB16-11N-07 | 1SBE111111R0711 | 16A | 400V AC/DC | 1NO+1NC | 3471523004504 |
| ESB16-11N-14 | 1SBE111111R1411 | 16A | 12V AC/DC | 1NO+1NC | 3471523004535 |
| ESB16-20N-01 | 1SBE111111R0120 | 16A | 24V AC/DC | 2NO | 3471523004337 |
| ESB16-20N-02 | 1SBE111111R0220 | 16A | 42V AC/DC | 2NO | 3471523004368 |
| ESB16-20N-03 | 1SBE111111R0320 | 16A | 48V AC/DC | 2NO | 3471523004399 |
| ESB16-20N-04 | 1SBE111111R0420 | 16A | 110V AC/DC | 2NO | 3471523004429 |
| ESB16-20N-05 | 1SBE111111R0520 | 16A | 240V AC/DC | 2NO | 3471523004450 |
| ESB16-20N-06 | 1SBE111111R0620 | 16A | 230V AC/DC | 2NO | 3471523004481 |
| ESB16-20N-07 | 1SBE111111R0720 | 16A | 400V AC/DC | 2NO | 3471523004511 |
| ESB16-20N-14 | 1SBE111111R1420 | 16A | 12V AC/DC | 2NO | 3471523004542 |
| Styczniki ESB20 | |||||
| ESB20-02N-01 | 1SBE121111R0102 | 20A | 24V AC/DC | 2NC | 3471523004559 |
| ESB20-02N-02 | 1SBE121111R0202 | 20A | 42V AC/DC | 2NC | 3471523004573 |
| ESB20-02N-03 | 1SBE121111R0302 | 20A | 48V AC/DC | 2NC | 3471523004597 |
| ESB20-02N-04 | 1SBE121111R0402 | 20A | 110V AC/DC | 2NC | 3471523004610 |
| ESB20-02N-05 | 1SBE121111R0502 | 20A | 240V AC/DC | 2NC | 3471523005358 |
| ESB20-02N-06 | 1SBE121111R0602 | 20A | 230V AC/DC | 2NC | 3471523005372 |
| ESB20-02N-07 | 1SBE121111R0702 | 20A | 400V AC/DC | 2NC | 3471523005396 |
| ESB20-02N-14 | 1SBE121111R1402 | 20A | 12V AC/DC | 2NC | 3471523004665 |
| ESB20-11N-01 | 1SBE121111R0111 | 20A | 24V AC/DC | 1NO+1NC | 3471523005310 |
| ESB20-11N-02 | 1SBE121111R0211 | 20A | 42V AC/DC | 1NO+1NC | 3471523005327 |
| ESB20-11N-03 | 1SBE121111R0311 | 20A | 48V AC/DC | 1NO+1NC | 3471523005334 |
| ESB20-11N-04 | 1SBE121111R0411 | 20A | 110V AC/DC | 1NO+1NC | 3471523005341 |
| ESB20-11N-05 | 1SBE121111R0511 | 20A | 240V AC/DC | 1NO+1NC | 3471523005365 |
| ESB20-11N-06 | 1SBE121111R0611 | 20A | 230V AC/DC | 1NO+1NC | 3471523005389 |
| ESB20-11N-07 | 1SBE121111R0711 | 20A | 400V AC/DC | 1NO+1NC | 3471523005402 |
| ESB20-11N-14 | 1SBE121111R1411 | 20A | 12V AC/DC | 1NO+1NC | 3471523005419 |
| ESB20-20N-01 | 1SBE121111R0120 | 20A | 24V AC/DC | 2NO | 3471523004566 |
| ESB20-20N-02 | 1SBE121111R0220 | 20A | 42V AC/DC | 2NO | 3471523004580 |
| ESB20-20N-03 | 1SBE121111R0320 | 20A | 48V AC/DC | 2NO | 3471523004603 |
| ESB20-20N-04 | 1SBE121111R0420 | 20A | 110V AC/DC | 2NO | 3471523004627 |
| ESB20-20N-05 | 1SBE121111R0520 | 20A | 240V AC/DC | 2NO | 3471523004634 |
| ESB20-20N-06 | 1SBE121111R0620 | 20A | 230V AC/DC | 2NO | 3471523004641 |
| ESB20-20N-07 | 1SBE121111R0720 | 20A | 400V AC/DC | 2NO | 3471523004658 |
| ESB20-20N-14 | 1SBE121111R1420 | 20A | 12V AC/DC | 2NO | 3471523004672 |
| Styczniki ESB25 | |||||
| ESB25-04N-01 | 1SAE231111R0104 | 25A | 24V AC/DC | 4NC | 4013614523915 |
| ESB25-04N-02 | 1SAE231111R0204 | 25A | 42V AC/DC | 4NC | 4013614523984 |
| ESB25-04N-03 | 1SAE231111R0304 | 25A | 48V AC/DC | 4NC | 4013614524059 |
| ESB25-04N-04 | 1SAE231111R0404 | 25A | 110V AC/DC | 4NC | 4013614524127 |
| ESB25-04N-06 | 1SAE231111R0604 | 25A | 230V AC/DC | 4NC | 4013614524196 |
| ESB25-04N-07 | 1SAE231111R0704 | 25A | 400V AC/DC | 4NC | 4013614524264 |
| ESB25-04N-14 | 1SAE231111R1404 | 25A | 12V AC/DC | 4NC | 4013614524332 |
| ESB25-13N-01 | 1SAE231111R0113 | 25A | 24V AC/DC | 1NO+3NC | 4013614523922 |
| ESB25-13N-02 | 1SAE231111R0213 | 25A | 42V AC/DC | 1NO+3NC | 4013614523991 |
| ESB25-13N-03 | 1SAE231111R0313 | 25A | 48V AC/DC | 1NO+3NC | 4013614524066 |
| ESB25-13N-04 | 1SAE231111R0413 | 25A | 110V AC/DC | 1NO+3NC | 4013614524134 |
| ESB25-13N-06 | 1SAE231111R0613 | 25A | 230V AC/DC | 1NO+3NC | 4013614524202 |
| ESB25-13N-07 | 1SAE231111R0713 | 25A | 400V AC/DC | 1NO+3NC | 4013614524271 |
| ESB25-13N-14 | 1SAE231111R1413 | 25A | 12V AC/DC | 1NO+3NC | 4013614524349 |
| ESB25-20N-01 | 1SAE231111R0120 | 25A | 24V AC/DC | 2NO | 4013614523939 |
| ESB25-20N-06 | 1SAE231111R0620 | 25A | 230V AC/DC | 2NO | 4013614524219 |
| ESB25-22N-01 | 1SAE231111R0122 | 25A | 24V AC/DC | 2NO+2NC | 4013614523946 |
| ESB25-22N-02 | 1SAE231111R0222 | 25A | 42V AC/DC | 2NO+2NC | 4013614524011 |
| ESB25-22N-03 | 1SAE231111R0322 | 25A | 48V AC/DC | 2NO+2NC | 4013614524080 |
| ESB25-22N-04 | 1SAE231111R0422 | 25A | 110V AC/DC | 2NO+2NC | 4013614524158 |
| ESB25-22N-06 | 1SAE231111R0622 | 25A | 230V AC/DC | 2NO+2NC | 4013614524226 |
| ESB25-22N-07 | 1SAE231111R0722 | 25A | 400V AC/DC | 2NO+2NC | 4013614524295 |
| ESB25-22N-14 | 1SAE231111R1422 | 25A | 12V AC/DC | 2NO+2NC | 4013614524363 |
| ESB25-30N-06 | 1SAE231111R0630 | 25A | 230V AC/DC | 3NO | 4013614524233 |
| ESB25-31N-01 | 1SAE231111R0131 | 25A | 24V AC/DC | 3NO+1NC | 4013614523960 |
| ESB25-31N-02 | 1SAE231111R0231 | 25A | 42V AC/DC | 3NO+1NC | 4013614524035 |
| ESB25-31N-03 | 1SAE231111R0331 | 25A | 48V AC/DC | 3NO+1NC | 4013614524103 |
| ESB25-31N-04 | 1SAE231111R0431 | 25A | 110V AC/DC | 3NO+1NC | 4013614524172 |
| ESB25-31N-06 | 1SAE231111R0631 | 25A | 230V AC/DC | 3NO+1NC | 4013614524240 |
| ESB25-31N-07 | 1SAE231111R0731 | 25A | 400V AC/DC | 3NO+1NC | 4013614524318 |
| ESB25-31N-14 | 1SAE231111R1431 | 25A | 12V AC/DC | 3NO+1NC | 4013614524394 |
| ESB25-40N-01 | 1SAE231111R0140 | 25A | 24V AC/DC | 4NO | 4013614523977 |
| ESB25-40N-02 | 1SAE231111R0240 | 25A | 42V AC/DC | 4NO | 4013614524042 |
| ESB25-40N-03 | 1SAE231111R0340 | 25A | 48V AC/DC | 4NO | 4013614524110 |
| ESB25-40N-04 | 1SAE231111R0440 | 25A | 110V AC/DC | 4NO | 4013614524189 |
| ESB25-40N-06 | 1SAE231111R0640 | 25A | 230V AC/DC | 4NO | 4013614524257 |
| ESB25-40N-07 | 1SAE231111R0740 | 25A | 400V AC/DC | 4NO | 4013614524325 |
| ESB25-40N-14 | 1SAE231111R1440 | 25A | 12V AC/DC | 4NO | 4013614524400 |
| Styczniki ESB40 | |||||
| ESB40-20N-01 | 1SAE341111R0120 | 40A | 24V AC/DC | 2NO | 4013614524592 |
| ESB40-20N-06 | 1SAE341111R0620 | 40A | 230V AC/DC | 2NO | 4013614524783 |
| ESB40-22N-01 | 1SAE341111R0122 | 40A | 24V AC/DC | 2NO+2NC | 4013614524608 |
| ESB40-22N-06 | 1SAE341111R0622 | 40A | 230V AC/DC | 2NO+2NC | 4013614524790 |
| ESB40-30N-01 | 1SAE341111R0130 | 40A | 24V AC/DC | 3NO | 4013614524615 |
| ESB40-30N-06 | 1SAE341111R0630 | 40A | 230V AC/DC | 3NO | 4013614524806 |
| ESB40-30N-07 | 1SAE341111R0730 | 40A | 400V AC/DC | 3NO | 4013614524844 |
| ESB40-31N-01 | 1SAE341111R0131 | 40A | 24V AC/DC | 3NO+1NC | 4013614524622 |
| ESB40-31N-06 | 1SAE341111R0631 | 40A | 230V AC/DC | 3NO+1NC | 4013614524813 |
| ESB40-40N-01 | 1SAE341111R0140 | 40A | 24V AC/DC | 4NO | 4013614524639 |
| ESB40-40N-02 | 1SAE341111R0240 | 40A | 42V AC/DC | 4NO | 4013614524660 |
| ESB40-40N-03 | 1SAE341111R0340 | 40A | 48V AC/DC | 4NO | 4013614524691 |
| ESB40-40N-04 | 1SAE341111R0440 | 40A | 110V AC/DC | 4NO | 4013614524721 |
| ESB40-40N-05 | 1SAE341111R0540 | 40A | 240V AC/DC | 4NO | 4013614524776 |
| ESB40-40N-06 | 1SAE341111R0640 | 40A | 230V AC/DC | 4NO | 4013614524820 |
| ESB40-40N-07 | 1SAE341111R0740 | 40A | 400V AC/DC | 4NO | 4013614524868 |
| ESB40-40N-08 | 1SAE341111R0840 | 40A | 415V AC/DC | 4NO | 4013614524899 |
| ESB40-40N-14 | 1SAE341111R1440 | 40A | 12V AC/DC | 4NO | 4013614524905 |
| Styczniki ESB63 | |||||
| ESB63-20N-01 | 1SAE351111R0120 | 63A | 24V AC/DC | 2NO | 4013614525247 |
| ESB63-20N-06 | 1SAE351111R0620 | 63A | 230V AC/DC | 2NO | 4013614525506 |
| ESB63-22N-06 | 1SAE351111R0622 | 63A | 230V AC/DC | 2NO+2NC | 4013614525513 |
| ESB63-22N-07 | 1SAE351111R0722 | 63A | 400V AC/DC | 2NO+2NC | 4013614525575 |
| ESB63-30N-06 | 1SAE351111R0630 | 63A | 230V AC/DC | 3NO | 4013614525520 |
| ESB63-30N-07 | 1SAE351111R0730 | 63A | 400V AC/DC | 3NO | 4013614525582 |
| ESB63-31N-04 | 1SAE351111R0431 | 63A | 110V AC/DC | 3NO+1NC | 4013614525414 |
| ESB63-31N-06 | 1SAE351111R0631 | 63A | 230V AC/DC | 3NO+1NC | 4013614525537 |
| ESB63-40N-01 | 1SAE351111R0140 | 63A | 24V AC/DC | 4NO | 4013614525278 |
| ESB63-40N-02 | 1SAE351111R0240 | 63A | 42V AC/DC | 4NO | 4013614525322 |
| ESB63-40N-03 | 1SAE351111R0340 | 63A | 48V AC/DC | 4NO | 4013614525377 |
| ESB63-40N-04 | 1SAE351111R0440 | 63A | 110V AC/DC | 4NO | 4013614525421 |
| ESB63-40N-05 | 1SAE351111R0540 | 63A | 240V AC/DC | 4NO | 4013614525483 |
| ESB63-40N-06 | 1SAE351111R0640 | 63A | 230V AC/DC | 4NO | 4013614525544 |
| ESB63-40N-07 | 1SAE351111R0740 | 63A | 400V AC/DC | 4NO | 4013614525605 |
| ESB63-40N-08 | 1SAE351111R0840 | 63A | 415V AC/DC | 4NO | 4013614525650 |
| ESB63-40N-14 | 1SAE351111R1440 | 63A | 12V AC/DC | 4NO | 4013614525667 |
| Styczniki ESB100 | |||||
| ESB100-20N-01 | 1SAE361111R0120 | 100 | 24V AC/DC | 2NO | 4013614533013 |
| ESB100-20N-06 | 1SAE361111R0620 | 100 | 230V AC/DC | 2NO | 4013614533037 |
| ESB100-40N-01 | 1SAE661111R0140 | 100 | 24V AC/DC | 4NO | 4013614533112 |
| ESB100-40N-06 | 1SAE661111R0640 | 100 | 230V AC/DC | 4NO | 4013614533211 |
